Overview
The Robinson R66 (Turbine) series type-training course includes both theoretical and practical elements for the Airframe and the Power plant.
The course covers the general maintenance and repair of the R66 helicopter and its engine. A thorough review and explanation of the R66 Maintenance Manuals are provided with emphasis on routine maintenance and repair.
Detailed description, operation, component location, removal, installation and troubleshooting to maintenance manual level.
The course complies with “type training up to and including level 3” as stated in Part 66 Appendix 111 and the course syllabus can be found below.
Language
Courses are taught in English only.
Course objectives
In addition to the information contained in Level 1 and 2 training, at the completion of level 3, the engineer will be able to:
- Demonstrate a theoretical knowledge of aircraft systems and structures and interrelationships with other systems, provide a detailed description of the subject using theoretical fundamentals and specific examples and to interpret results from various sources and measurements and apply corrective action where appropriate.
- Perform system, engine, component and functional checks as specified in the maintenance manual.
- Demonstrate the use, interpret and apply appropriate documentation including structural repair manual, troubleshooting manual, etc.
- Correlate information for the purpose of making decisions in respect of fault diagnosis and rectification to maintenance manual level.
- Describe procedures for replacement of components unique to aircraft type.
On completion of the theoretical and practical training courses the student shall be able to demonstrate, to the levels identified in the Appendix III syllabus, the detailed theoretical knowledge of the aircraft applicable systems, structures, operations, maintenance, repair and troubleshooting according to approved maintenance data. The student shall be able to demonstrate the use of manuals special tools and equipment and approved procedures, including the knowledge of relevant inspections and limitations.
Course examination
Examination will take place at the end of the Type training course.
- The type training examination standard is to PART 66 Appendix 111 “Type Training and examination Standard”.
- The post course examination is of the multiple-choice type format.
- The examination is of the closed book type, where no reference material is permitted.
- The examination pass mark is 75%.
- There is no penalty marking.
As well as a minimum 75% examination pass mark, a 90% course attendance has also to be obtained before the student is issued with a Certificate of Recognition.
Duration – 15 days in total
Theoretical element (days 1-10):
The total theoretical instructional hours will be 60 hours over a 10 working day period. The course days have a total of 6 hours of instruction with 3 hours of instruction given in the morning and 3 hours of instruction given in the afternoon; this does not include tea or lunch breaks, revision, aircraft walk around or the examination.
The theoretical course schedule below breaks the course in to modules/chapters taught by day number and morning and afternoon periods. A day's instruction commences at 08:30 and is complete by 16:10. It is recommended that students should arrive at least 15 minutes early each morning. A day is sectioned into the following periods:
- Period 1 is from 08:30 to 10:00
- Period 2 is from 10:20 to 12:00
- Period 3 is from 13:00 to 14:30
- Period 4 is from 14:50 to 16:10
Practical element (days 11-15):
The total practical instructional hours will be 30 hours over a 5 working day period. The course days have a total of 6 hours of instruction, with 3 hours of instruction given in the morning and 3 hours of instruction given in the afternoon; this does not include tea or lunch breaks, revision, or the examination.
Location
Sloane Helicopters, Sywell Aerodrome, Northampton, UK
Theoretical syllabus (days 1-10)
The total theoretical instructional hours will be 60 hours over a two (2) working week (10 working day) period.
| Chapter of manual | Helicopter Turbine B1 Level Mechanical | Time |
|---|---|---|
| General overview Introduction to the Robinson R66 series (PowerPoint Presentation) |
Level 1 | Morning |
| 05. Time limits/components maintenance checks | Level 1 | Morning |
| 06. General aircraft (dimensions/weights, mtow etc) | Level 1 | Morning |
| 07. Lifting & Shoring | Level 1 | Afternoon |
| 08. Leveling & Weighing | Level 1 | Afternoon |
| 09. Towing & Taxing | Level 1 | Afternoon |
| 10. Parking/mooring, Storing & Returning to Service | Level 1 | Afternoon |
| Chapter of manual | Helicopter Turbine B1 Level Mechanical | Time |
|---|---|---|
| Continued from Day 1 10. Parking/mooring, Storing & Returning to Service |
Level 1 | Morning |
| 11. Placards & Markings | Level 1 | Morning |
| 12. Servicing | Level 1 | Morning & afternoon |
| 20. Standard practices | Level 1 | Afternoon |
| 65. Tail rotor drive | Level 3 | Afternoon |
| Subject | Helicopter Turbine B1 Level Mechanical | Time |
|---|---|---|
| Helicopters | ||
| 64. Tail rotor | Level 3 | Morning |
| 53. Airframe structure (helicopter) | Level 3 | Morning |
| 25. Emergency floatation equipment | Level 3 | Morning |
| Zonal and station identification systems | Level 3 | Morning |
| 62. Rotors | Level 3 | Afternoon |
| 63. Rotor drives | Level 3 | Afternoon |
| Subject | Helicopter Piston Turbine B1 Level Mechanical | Time |
|---|---|---|
| Continued from Day 3 62. Rotors |
Level 3 | Morning |
| 18. Vibration & noise analysis (blade tracking) |
Level 3 | Afternoon |
| Subject | Helicopter Turbine B1 Level Mechanical | Time |
|---|---|---|
| Continued from Day 4 18. Vibration & noise analysis |
Level 3 | Morning |
| 67. Rotor flight control | Level 3 | Afternoon |
| Subject | Helicopter Turbine B1 Level Mechanical | Time |
|---|---|---|
| Airframe systems | ||
| 21. Air conditioning | Level 3 | Morning |
| 23. Communications | Level 2 | Morning |
| 24. Electrical power | Level 3 | Morning & afternoon |
| 25. Equipment & furnishings | Level 3 | Afternoon |
| 28. Fuel systems | Level 3 | Afternoon |
| Subject | Helicopter Turbine B1 Level Mechanical | Time |
|---|---|---|
| 26. Fire protection | Level 3 | Morning |
| 28a. Fuel systems – monitoring & indicating | Level 3 | Morning |
| 32. Landing gear | Level 3 | Morning |
| 52. Doors & windows | Level 3 | Morning |
| Turbine engine | ||
| 70. Standard practices | Level 3 | Morning |
| 70a. Constructional arrangement etc. | Level 3 | Afternoon |
| Subject | Helicopter Turbine B1 Level Mechanical | Time |
|---|---|---|
| Continued from Day 7 70a. Constructional arrangement etc. |
Level 3 | Morning |
| 70b. Engine performance | Level 3 | Afternoon |
| 71. Power plant | Level 3 | Afternoon |
| 73. Engine fuel & control | Level 3 | Morning & afternoon |
| Subject | Helicopter Turbine B1 Level Mechanical | Time |
|---|---|---|
| 74. Ignition | Level 3 | Morning |
| 75. Bleed air | Level 3 | Morning |
| 76. Engine control | Level 3 | Afternoon |
| Subject | Helicopter Turbine B1 Level Mechanical | Time |
|---|---|---|
| 76. Engine indication | Level 3 | Morning |
| 78. Exhaust | Level 3 | Morning |
| 79. Oil | Level 3 | Morning |
| 80. Starting | Level 3 | Morning & afternoon |
| 83. Accessory gear boxes | Level 3 | Afternoon |
Practical syllabus (days 11-15)
The total practical instructional hours will be 30 hours over a (1) working week period.
If you have any questions or require information on course tariffs then please contact us. If you wish to enrol in this course then please click here for an application form.
